28 en | Installation
3.6

Installing the AC terminal block

Warning!
When installing the power supply, ensure that the ground wire from the MAP terminal block
!
is connected to the grounding stud.
The ground wire from the MAP terminal block to the power supply does not provide an
earth ground for the enclosure. It only provides an earth ground for the power supply.
Warning!
Electricity
!
Once the terminal block connected to the MAP terminal block has been put into the power
supply, do not remove it anymore. Never remove the terminal block connected to the MAP
terminal block from the power supply during operation.
1.
2.
3.
3.7

Installing the thermistor cable

The thermistor cable is used to adjust the battery charge voltage to compensate for the air
temperature around the batteries.
1.
2.
2024-10 | V26 | F.01U.168.332
Mount the ICP-MAP0065 MAP terminal block to the enclosure back wall into the
corresponding mounting holes and secure it with the supplied screws.
Plug the terminal block connected to the MAP terminal block into the power.
Connect the ground wire to the grounding stud of the enclosure back.
Plug the thermistor cable into the power supply to the terminal marked
Mount the thermistor on the inside rear of the enclosure right on the top of the two
batteries.
Installation manual
Modular Alarm Platform 5000
1
2
3
Bosch Security Systems B.V.
.
