Class 1
Class 2
Class 3
Class 4
Class 5
Class 6
Table 9.7: Communicator types
9.4

Alarm reporting

ICP-MAP5000-COM and ICP-MAP5000-SC have an integrated alarm reporting functionality.
It can be used for alarm transmission systems according to EN50136-2 SP4 or DP3. For DP3
compliant transmission, the alternate transmission path has to be wireless.
In case of a fault on the primary connection to a receiver, ICP-MAP5000-COM and ICP-
MAP5000-SC are connecting to a backup receiver using the alternate transmission path.
The fault on the primary path is reported to the backup receiver and displayed on the touch
keypad.
ICP-MAP5000-COM and ICP-MAP5000-SC can report to any alarm receiver supporting the
following protocols:
–
–
–
Transmission path faults are directly reported to the user via the MAP5000 touch keypad.
ICP-MAP5000-COM and ICP-MAP5000-SC have implemented layer 1 supervision for Ethernet
and wireless path.
ICP-MAP5000-COM and ICP-MAP5000-SC supervise the link to Ethernet and poll the
wireless network on checking for connection, signal strength and sign in status.
The communicator in ICP-MAP5000-COM and ICP-MAP5000-SC is realized as a pass-through
system.
The monitoring center, to which the MAP5000 panel is connected to, has to provide proof of
availability of the alarm transmission system.
For information security purposes, ICP-MAP5000-COM and ICP-MAP5000-SC provide the
possibility of encrypted transmission (AES 128, 192, 256).
To grant anti-substitution security, the initial key has to be provided manually by typing it
into the configuration software RPS for MAP.
9.5

History log

The history log of the MAP5000 panels can be configured for 500 to 5000 entries using RPS
for MAP.
For the SPT functionality, an additional history log of 1000 entries is available.
2024-10 | V26 | F.01U.168.332
AÜA-B25
AÜA-B5
AÜA-S180
AÜA-S20
VdS 2465-S2
SIA DC-09 (TCP/IP and UDP/IP)
Conettix IP
Demand-driven connection with 25-hourly function
monitoring and voice annunciation
Demand-driven connection with 25-hourly function
monitoring and simple digital transmission
Demand-driven connection with 25-hourly function
monitoring and digital transmission
Demand-driven connection with 5-hourly function
monitoring and digital transmission
Existing connection with 180-second function monitoring
and digital transmission
Existing connection with 20-second function monitoring and
digital transmission
