Modular Alarm Platform 5000
Maintenance category permissions
May adjust touch keypad volume/brightness
May change output state
May set date time
May test bell
May test motion detectors
May walk test automatic points
May walk test points
Table 9.6: SES Permissions
* also with Duress PIN
Refer to
–
–
9.3.5

Tamper surveillance

Tamper switch with wall tamper
4
Location supervision of the panel
External alarm signaling by means of siren and/or remote alarm signaling with
communicator must be planned in accordance with Sirens and communicator in accordance
with EN50131 grade 3, page 70.
1.
2.
Design types of the communicators according to SES
The transmission paths for remote alarm signaling are divided into the following:
–
–
Types
EN 50131
Bosch Security Systems B.V.
Installer button, page 72
Manufacturer authorization, page 66
When mounting the enclosure and installing the tamper switch, take the wall tamper of
the MAP5000 panel into account (refer to Mounting the enclosure, page 22 and Installing
and connecting the tamper switch, page 57).
In case of variants A, B and C with communicator(s) of classes 3 and 4, provide location
supervision for the MAP5000 panel as soon as one or more areas are armed.
It is possible to omit location supervision for variant D with class 5 communicator.
Realize the location supervision as a technical solution by the intrusion alarm system
itself. Therefore, ensure the EN-compliance of the requirements for disarming.
Or:
Realize the location supervision by security-relevant persons who guarantee that
actions that pose a risk to security are detected at all times at the time of the required
location supervision.
Demand-driven connection with 25-hourly (AÜA-B25) or 5-hourly function monitoring
(AÜA-B5)
Existing connection with 3-minute (AÜA-S180) or 20-second function monitoring (AÜA-
S20)
SES
Transmission procedure
Installation manual
Appendices | en
1 2A 2B 3
X X
X X
X
X X
X X X
X
X
