Modular Alarm Platform 5000
9

Appendices

This chapter contains information and instructions for creating programming that complies
with the requirements of a specific standard.
Notice!
i
Use the default setting for parameters that are not explicitly mentioned in this description.
In addition, the instructions for MAP5000 panel validation in the RPS for MAP must be
followed.
9.1

Requirements in accordance with VdS class C

9.1.1

Selecting the default setting

4
Refer to
–
9.1.2

Power supply for areas

Refer to Connecting the LSN gateway, page 52.
9.1.3

Touch keypads

Refer to:
–
–
–
9.1.4

Connection to a management system

Refer to IP Interface, page 62.
9.1.5

Printer connection

Connecting the supported printer is permitted only for service purposes.
9.1.6

Access levels

The standard distinguishes between four access levels (AE):
–
–
–
–
Selecting the access level
AE 1 Access for everyone, no authorization/code required
AE 2 Access for users, user passcode required
AE 3 Access for installers via touch keypad
1.
2.
AE 3 Access for installers via RPS for MAP
Bosch Security Systems B.V.
Select VdS class C as the default property values setting.
Standard-compliant programming, page 65
Connecting the touch keypad, page 55
Planning the system with power supply, page 9
Planning the system with BDB/CAN splitter, page 13
AE 1 Access for everyone, no authorization/code required
AE 2 Access for users, user passcode required
AE 3 Access for installers via touch keypad or via RPS for MAP
AE 4 Access for manufacturers via RPS for MAP
Open MAP panel enclosure.
Switch to installer mode (refer to Installer button, page 72).
Enter installer passcode.
Installation manual
Appendices | en
2024-10 | V26 | F.01U.168.332
