Modular Alarm Platform 5000
The following applies for VdS
For remote operation of the IPP-MAP0005-2 MAP power supply 150W, a touch keypad
assigned to the same area must be provided for indication of power supply trouble (trouble
in mains supply / battery).
2.4.2

Planning the system with BDB/CAN splitter

4
Wiring with a MAP BDB/CAN splitter and a MAP LSN gateway
Callout
1
2
Wiring with two MAP BDB/CAN splitters
Callout
Bosch Security Systems B.V.
When using a MAP BDB/CAN splitter to split the external BDB into two independent
areas, chose one of the following wiring possibilities:
1
Description
ICP-MAP0012 MAP BDB/CAN splitter
ICP-MAP0010 MAP LSN gateway
1
Description
Installation manual
Introduction | en
2
1
2024-10 | V26 | F.01U.168.332
13
