36
en | Installation
Analog AT x000 to the power converter connections
Callout
1
2
3
3.13
Installing the hinged mounting plate
4
2024-10 | V26 | F.01U.168.332
Description
IPP-MAP0005-2 MAP power supply 150W
ICP-MAP0017 12 MAP 12V-28V power converter
AT x000 communicator
Install the ICP-MAP0025 hinged mounting plate inside the enclosure ICP-MAP0111 or
ICP-MAP0120.
Installation manual
Modular Alarm Platform 5000
Bosch Security Systems B.V.
