Front View - Delta Modulon DPH Series User Manual

2.5

Front View

On the front of the UPS, there are a 10" color touch panel, a tri-color LED indicator, a
door switch, six casters and four leveling feet. Please see
10'' Color
Touch Panel
1. For information about the 10" color touch panel, please refer to
Settings
.
2. For information about the tri-color LED indicator, please refer to
Indicator & Buzzer
3. The caster at the bottom of the UPS can be used to move over short distances,
and the leveling feet fix and stabilize the UPS on the ground. Please refer to
5.3 UPS Transportation
4. Please refer to
Caster
Figure 2-2: Front View
.
for relevant information.
Figure 2-3
for how to open the UPS front door.
Figure 2-2
Tri-color LED
Indicator
Door Handle
Leveling Feet
.
7. LCD Display &
2.8 Tri-color LED
15
