For STS module illustration, please refer to
Handle
5.7.1

STS Module Installation

NOTE:
1. Only qualified service personnel can perform the following STS module
installation procedures.
2. The STS module is heavy (> 25 kg (55.12 lb)). At least two people are
required for handling.
Step 1
Confirm that the STS module's switch is in the lower position (
Figure 5-24: Confirm the STS Module's Switch in the Lower Position
Delta UPS DPH 50-200kVA
LED Indicator
Switch
Figure 5-23: STS Module
Figure 5-23
.
Handle
).
74
