No.
UPS
❶
User Manual
❷
Test Report
❸
Parallel Cable
❹
RS-232 Cable
❺
USB Cable
❻
Key (placed inside the UPS cabinet)
❼
M10 Screw (used for input/ output/ battery wiring)
❽
4-Pin Dry Contact Terminal Block (used for REPO dry
❾
contacts)
6-Pin Dry Contact Terminal Block (used for Modbus and BMS
❿
ports)
8-Pin Dry Contact Terminal Block (used for (1) external
battery temperature detection and (2) external switch/
⓫
breaker status dry contacts)
10-Pin Dry Contact Terminal Block (used for input/ output dry
⓬
contacts)
2.3 Functions & Features
• Hot-swappable STS module, communication interfaces and power modules
(optional) realize on-line maintenance and reduce the MTTR (Mean Time to
Repair).
• Input power factor > 0.99 and input THDi < 3% save on installation cost and
diminish power contamination.
• Output power factor=1.
• Efficiency > 96.5% saves on operation cost.
• Automatic input frequency detection enables operation at 40Hz to 70Hz.
Delta UPS DPH 50-200kVA
Item Q'ty
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
2 PCS
36 PCS
1 PC
1 PC
2 PCS
2 PCS
12
