WARNING:
You must stabilize the UPS with the four provided balance brackets.
Otherwise, the UPS might tip over.
Screw M10 x 4
Screw M12 x 2
Washer Plain x 2
Washer Spring x 2
Figure 5-3: Balance Bracket Installation_ Front of the UPS
Screw M10 x 4
Screw M12 x 2
Washer Plain x 2
Washer Spring x 2
Figure 5-4: Balance Bracket Installation_ Rear of the UPS
NOTE:
Please contact Delta service personnel for the expansion nuts. The four
balance brackets and the four M12 screws are already provide with the UPS.
Balance Bracket x 2
Expansion Nut M12 x 2
Balance Bracket x 2
Expansion Nut M12 x 2
Ground
Ground
