Rear View - Delta Modulon DPH Series User Manual

No.
For detailed information about the communication interface, please refer to
1
Communication Interfaces
Please follow on-site requirements to install the correct number of power
modules (optional). Please refer to
2
information.
For detailed information about STS module, please refer to
3
The UPS has four breakers, which are Input Switch (Q1), Bypass Switch (Q2),
Manual Bypass Switch (Q3) and Output Switch (Q4). Please refer to
4
for the location of the four breakers.
For how to turn on/ off each switch, please refer to below Figure.
4
2.7

Rear View

WARNING:
Only authorized Delta engineers or service personnel can perform
installation, wiring, panel & cover removal, maintenance and operation. If you
want to execute any action mentioned above by yourself, the action must be
under the supervision of authorized Delta engineers or service personnel.
Delta UPS DPH 50-200kVA
Description
.
5.8 Power Module (Optional)
4.
for relevant
5.7 STS Module
.
Figure 2-
18
