No. Icon/ Text
16
17
18
19
20
Text/
Button Symbol
Digital
Function
Display
(Yes or
(Yes or
No)
No)
✓ ✓
✓
✓ ✓
Display
(Yes or
No)
1. Indicates battery status (Green:
Normal/ Flashing Green & Gray:
Battery Mode/ Flashing Red & Gray:
Battery Not Connected).
2. Shows battery remaining capacity
✓
(%) and battery remaining time
(minutes).
3. Battery status screen shortcut
button.
Indicates bypass static switch status
✓
(Green: ON/ Gray: Abnormal or OFF).
Indicates rectifier status (Green:
✓
Normal/ Gray: Waiting or OFF).
1. Indicates inverter status (Green:
Normal/ Gray: Waiting or OFF).
✓
2. Inverter output screen shortcut
button.
1. Indicates output status (Green:
Normal/ Gray: No Output).
✓
2. Shows load capacity (%).
3. UPS output screen shortcut button.
Description
