7.7.5

Clear

Path: → Clear
Item
Clear Statistics
Clear Historical
Event
Clear Battery
Test Result
Clear Kilowatt
Hour (kWh)
NOTE:
The records mentioned above are important information for system analysis
and maintenance. Do not clear any of them without the consent of qualified
service personnel.
7.7.6

Advanced Diagnosis

Path: → Advanced Diagnosis
After entering the ADVANCED DIAGNOSIS screen, you can check:
1. STS temperature, battery temperature, and fan speed of the system.
2. INV temperature and PFC temperature of a specific power module.
Item
STS Temp. (°C)
System
Battery Temp. (°C)
Fan Speed (rpm)
INV Temp. (°C)
Power
Module
PFC Temp. (°C)
Delta UPS DPH 50-200kVA
After you select 'Clear' and confirm clearance of statistics, all
records of the statistics will be cleared.
After you select 'Clear' and confirm clearance of historical
event logs, all historical event logs will be cleared.
After you select 'Clear' and confirm clearance of battery test
result, the battery test result will be cleared.
After you select 'Clear' and confirm clearance of kilowatt hour
records, the kilowatt hour statistics will be cleared.
Sub Item
Description
Description
Shows the STS module's SCR
temperature.
Shows the batteries' temperature.
Shows the fan speed.
Shows a specific power module's inverter
temperature.
Shows a specific power module's PFC
temperature.
132
