NOTE:
Table 5-4
1.
different number of batteries, please contact Delta service personnel for
the protective device's current and voltage values.
2. If you need to parallel multiple units of external battery cabinets, please
contact Delta service personnel for relevant information.
3. To extend the backup time, you can parallel up to four units of external
battery cabinets to the UPS. Please note that (1) the number of batteries
in each paralleled external battery cabinet shall be the same and that (2)
the cable length of each battery string shall be the same.
• When choosing the external battery cabinet's protective device, please take the
following factors into consideration: (1) overcurrent between the UPS and battery
circuit, (2) short circuit current of the batteries, (3) wire/ cable materials, and (4)
local electrical regulations. If you have any questions about the external battery
cabinet's protective device, please contact Delta service personnel.
• The protective device is optional, and its type must be fast-acting DC circuit
breaker and/ or fast-acting DC fuse. If you want to buy any of them, please contact
Delta service personnel. When choosing the protective device, follow the
instructions below.
(1) The protective device's rated current must comply with the current values
Table 5-4
shown in
(2) The specifications of the protective device's short-circuit protection (i.e. the
tripping current of the fast-acting DC circuit breaker and/ or the melting current
of the fast-acting DC fuse) must be 4 ~ 6 times the values shown in
Besides, the response time of the protective device must be less than 20ms.
(3) For the choice of the fast-acting DC fuse mentioned above, the A50QS series
from the supplier
service for relevant information.
(4) The maximum tripping current of the fast-acting DC circuit breaker and/ or the
maximum melting current of the fast-acting DC fuse mentioned above are 6
times as much as the values shown in
suggested for general applications only. For the actual maximum values, the
maximum short-circuit capacity of the on-site batteries must be taken into
consideration. Please contact Delta customer service for relevant information.
Delta UPS DPH 50-200kVA
is for 12Vdc × 40 PCS of batteries (default). If you install a
.
Ferraz Shawmut
is suggested. Please contact Delta customer
Table 5-4
. These maximum values are
Table 5-4
.
