Delta Modulon DPH Series User Manual page 135

No. Item
Battery
7 Management
System (BMS)
Multifunctional
8 Communication
Card (MFC)
NOTE:
For installation and operation details, please refer to the
Manual
included in the package of the optional accessory. To purchase any
accessory mentioned above, please contact your local dealer or customer
service.
If you use the lead-acid batteries, it is recommended to
install the BMS to monitor (1) each battery's voltage, (2)
each battery string's voltage and charging/ discharging
current, and (3) battery environment temperature.
The BMS should be connected to the UPS's BMS port
located at the rear of the touch panel (see
Figure 4-19
and ). For details, please refer to
Function on the LCD Screen
Setting
.
NOTE:
The quantity of BMS to be installed depends on
how many external battery cabinets (lead-acid
batteries) are connected to the UPS. For BMS
installation, please contact Delta customer
service.
If you use the Delta lithium-ion batteries, you must
purchase and install the multifunctional communication
card (MFC) in the SMART slot shown in
monitor the battery status via the UPS's LCD. For relevant
information, please refer to
Screen
. Please contact Delta customer service if you
need more information.
NOTE:
For parallel UPSs, you must install one
multifunctional communication card (MFC) in
each parallel UPS if you use the Delta lithium-
ion batteries.
Function
7.6.4 Battery & Charging
and
8.3 MFC Function on the LCD
Quick Guide
Figure 4-18
8.2 BMS
Figure 4-1
to
User
or
135
