No. Item
②
Temperature
③
Humidity
DI1
DI2
④
DI3
DI4
Connecting the Optional EMS 1000 (EnviroProbe)
⚫
1. Each UPS can be connected with a maximum of 16 EMS 1000 (EnviroProbe)
devices in string to expand the environment monitoring range. A maximum of three
UPS units can be paralleled. Please use a CAT-5 cable (user-supplied & the cable
length depends on the on-site application and environment) to connect the EMS
1000 (EnviroProbe) to the EMS port on the UPS. For the location of the EMS port,
Figure 4-18
please see
2. The UPS only supports RS485 communication. When installing the EMS 1000
(EnviroProbe), please set the device's communication mode as RS485 following
1 Comm DIP Switch Settings
3. When installing, please set the ID # by the four ID DIP switches on the left of the
device following
NOTE:
The ID # of each EMS 1000 (EnviroProbe) device connected to the UPS must
be different so that the UPS can identify each device.
Color
(Status)
Green (Normal)
Yellow
(Warning)
Red (Alarm)
Green (Normal)
Yellow
(Warning)
Red (Alarm)
Green (None/
Information)
Yellow
(Warning)
Red (Alarm)
.
of the
3-2 ID DIP Switch Settings
Descriptions
Shows the statuses of Temperature/
Humidity based on the EMS settings.
Green (Normal): lower than the set
⚫
Warning value.
Yellow (Warning): higher than the set
⚫
Warning value, but lower than the set
Alarm value.
Red (Alarm): higher than the set Alarm
⚫
value.
If Red (Alarm)/ Yellow (Warning) is triggered,
the status will recover only when the
detected value is lower than the Recovery
value.
1. Shows the statuses of the input contacts.
2. The Title, NO/ NC, and Event Type can be
adjusted according to your needs.
EnviroProbe 1000 Quick Guide
EnviroProbe 1000 Quick Guide
