Delta Modulon DPH Series User Manual page 141

Item
BMS Model
Name
Address
Type
Status
2. Select 'CM-TA' in the BMS Model list, you can view the Alarm Threshold Values
(High & Low)*
Temperature.
You can also set up the following items. These settings must be carried out by
qualified service personnel. Please contact Delta customer service for assistance.
NOTE:
1. * The Alarm Threshold Values (High & Low) are defined by the service
1
personnel during the installation process of the optional battery
management system (BMS).
Item
BMS Model
Name
Address
Status
Select CM/ CM-TA
Select Main/ Ext #n module.
Set the module address.
Set the module type as Voltage Type/ Internal Resistance.
'Enable/ Disable' the display of the Main and Ext #n modules'
information on the BMS screen.
of Cell Voltage, String Voltage, Cell Temperature and Ambient
1
Select CM/ CM-TA
Select String 1-6.
Set the module address.
'Enable/ Disable' the display of the String 1-6's information on
the BMS screen.
Description
Description
141
