4.1.12
Battery Start Buttons
For the battery start buttons' operation information, please refer to
Start-up Procedures
Delta UPS DPH 50-200kVA
Figure 4-15: Location of the Auxiliary Power Cards
.
Figure 4-16: Location of the Battery Start Buttons
Auxiliary
Auxiliary
Power
Power
Card's LED
Card
Indicator
Auxiliary
Auxiliary
Power
Power
Card
Card's LED
Indicator
6.2.2 Battery Mode
Battery Start Button
Battery Start Button
40
