No. Item
4 Search Tick
Present/ Peak/
5
Low/ Sum (kWh/d)
6 Last Reset Date
7.6

UPS Settings

This chapter lists all the UPS setting items for your reference (not including the setting
items for the optional accessories). Some items will show up only under certain
conditions. Please refer to
7.6.1

Bypass Setting

Path: → Bypass Setting
Item
Bypass Frequency Range
Bypass Voltage (Max.)
Bypass Voltage (Min.)
ECO Voltage Range
Shows the date and time that has been set via ( ).
Regardless of different kWh statistics sheets, these
four items only indicate today's statistics: the
present value/ the highest value (so far)/ the lowest
value (so far)/ the sum (so far).
The last date when 'Clear Kilowatt Hour' was
executed.
7.1 LCD Display Hierarchy
Set up the bypass output's frequency range.
Set up the bypass output's maximum voltage.
Set up the bypass output's minimum voltage.
Set up the bypass output's voltage range in ECO
mode.
Description
for details.
Description
119
