No.
1 None
2 Generator Status
3 Battery Ground Fail
External Battery Breaker
4
Detection
5 Charger Off (Positive)*
6 Charger Off (Negative)*
Battery Abnormal
7
Shutdown
8 Input Transformer OTW
9 Output Transformer OTW
10 Battery Fuse Open
11 Charge Off*
NOTE:
* If you use non-Delta lithium-ion batteries, you must set up Charger Off
1
(Positive), Charger Off (Negative) and Charger Off these three items. Please
7.6.6 Dry Contact Setting
refer to
lithium-ion batteries, please refer to
information, please contact Delta customer service.
Delta UPS DPH 50-200kVA
Event
1
1
1
Description
No set-up.
Generator status detection.
Battery leakage detection.
Status detection of the external battery
cabinet's breaker or switch.
Turn off the charger (positive).
Turn off the charger (negative).
Battery Abnormal Shutdown
Input Transformer over temperature warning
Output Transformer over temperature
warning
Battery Fuse status detection
Turn off the charger (total)
. For settings relevant to the non-Delta
7.6.4 Battery & Charging Setting
. For more
