B. For dual input and bottom wiring application, follow
removed four copper bars in the designated areas. Please secure the eight nuts
tightly.
90 °
x 4
Cooper Bar
Install the Four
Cooper Bars
Figure 5-8: Install the Four Copper Bars and Secure the Eight Nuts_
NOTE:
Please keep the removed nuts and cables properly for future use. If you want
to modify the UPS from dual input into single input, please reverse the
procedures mentioned above.
5.5.3

Single Unit Wiring

NOTE:
Before wiring, please read
conditions have been met.
Table 5-3
Refer to
diagrams and instructions, please refer to the following sections.
Table 5-3: UPS's Wiring Terminals & Wiring Information
No. Item
AC Input Terminals
1
(L1/ L2/ L3/ N)
Tightening Torque=150 ± 10 Kgf-cm (130.2 ± 8.7Ib-in)
for Dual Input & Bottom Wiring Application
5.5 Wiring
for information about the wiring terminals and wiring. For the wiring
Connect to the main AC source.
Figure 5-8
Secure the
Eight Nuts
Tightly
Different
Angle
thoroughly and make sure that relevant
Function
to install the
55
