4.2
Communication Interfaces (II): at the Rear of the Touch
Panel
No.
Item
RESET
❶
MODBUS
❷
(RS-485 Port)
Figure 4-17: Communication Interfaces (II)
Press the RESET button to restart the LCD.
1. Provides Modbus RTU communication service.
2. Connects to a user-supplied monitoring system.
Description
41
