2.5

Front View

On the front of the UPS, there are a 10" color touch panel, a tri-color LED indicator, a door
switch, four casters and four leveling feet. Please see Figure 2-2.
10" Color Touch Panel
Modulon DPH Series
600mm
(33.46")
(23.62")
(Figure 2-1: Exterior and Dimensions)
Levelling Feet
(Figure 2-2: UPS Front View)
2-6
1445mm
(56.89")
850mm
Tri-color LED Indictor
Door Switch
Levelling Foot
Casters
