• External Battery Cabinet Alarm
When any external battery cabinet connected to the UPS has the following problems,
the UPS system will sound an alarm. Please see the table below.
No. External Battery Cabinet Status
1 Battery Abnormal - Reversed
2 Battery Ground Fault
3 Battery Over Temperature
4 Battery Under Temperature
5 Battery Breaker Off
6 Battery Disconnected (Missing)
7 Battery Over Charged
8 Battery Test Fail
9 Battery End of Discharge
Imminent
10 Battery End of Discharge
11 Battery Life Time Expired
Delta UPS DPH 50-200kVA
Alarm
Sounds 0.5 second every second.
Sounds 0.5 second every second.
Sounds 0.5 second every second.
Sounds 0.5 second every second.
Sounds 0.5 second every 3 seconds.
Sounds once every second.
Long beep.
Sounds 0.5 second every second.
Sounds 0.5 second every second.
Long beep.
Sounds 0.5 second every 3 seconds.
