Delta Modulon DPH Series User Manual page 114

No. Icon/ Text
11
12
/
13
14
15
Delta UPS DPH 50-200kVA
Text/
Button Symbol
Digital
Function
Display
(Yes or
(Yes or
No)
No)
✓
✓
✓
✓
✓
Display
(Yes or
No)
Tap the button to check the status of
each power module, parallel
communication card, system control
card, and auxiliary power card. For
more information, please refer to
Power Flow, Summary, System Status &
EMS
.
Tap the button to check the EMS
status. To enable the function, you
have to connect an optional EMS 1000
(EnviroProbe) to the UPS and complete
relevant settings. For details, refer to
Optional Accessories
ON/ OFF Button. The gray icon (
indicates that the inverter is OFF.
✓
The green icon (
power-on process is completed and
the inverter is ON.
1. Indicates bypass input status
(Green: Normal/ Red: Abnormal or
OFF).
✓
2. Bypass input screen shortcut
button.
1. Indicates main input status (Green:
Normal/ Red: Abnormal or OFF).
✓
2. Main input screen shortcut button.
Description
.
) indicates that the
7.8
8.
)
114
