LC Filter

7.13.3
When regenerative or low-harmonic functionality is required in an application, install an LC or LCL Filter between the power supply
and the system module. The LC Filter can be used with the AFE module or the grid converter module, and it ensures correct power
quality and minimal interruption to the grid. Use the LC Filter when one dedicated transformer serves each system module. The LC Filter
is designed for the nominal AFE/GC switching frequency. It is safe to increase the switching frequency, but decreasing the switching
frequency below nominal value increases the risk of overheating and unwanted resonances.
Use aR-type AC fuses with the LC Filter. The recommended fuse types can be found in
AC, IP00/Open Type. Select the fuses according to the frame and the current rating of the system module. When designing the
10.3.1 Wiring Diagram, AFE/GC, AR10L
fuse installation, refer to

DC Filter

7.13.4
The DC/DC converter requires a DC Filter inductance between the source and the system module for current control and ability to boost
voltage. The filter also smoothens the current and voltage waveform, making them suitable for most DC sources or loads.
It is safe to increase the switching frequency which further reduces the current and voltage ripple at the DC source. Decreasing the
switching frequency below the nominal value increases the risk of overheating.
The total capacitance of the capacitors in the DC Filter (capacitance between + and - terminals of DC Filter):
DC Filter, 570 A = 180 µF
l
DC Filter, 1200 A = 480 µF
l
Use aR-type DC fuses with the DC Filter. The recommended fuse types can be found in
Converter, IP00/Open Type. Select the fuses according to the frame and the current rating of the system module. When
designing the fuse installation, refer to
Converter, DR12L.

AuxBus Communication

7.14

Usage of AuxBus

7.14.1
AuxBus enables communication for filters. When AuxBus is connected, the drive provides temperature monitoring and other diagnostics
of the used options thus giving vital information about the system. AuxBus is also used to create warning and fault signals for the system
if the drive operates outside the set limits or if there is a failure.
For the drive/converter to be able to protect the filters, AuxBus must be connected.
