Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions of the I/O and Relay Option
10.2.22
9.8
(0.38)
Ø4.8
(0.19)
Ø4
(0.16)
Figure 149: Dimensions of the I/O and Relay Option in mm (in)
148
| Danfoss Drives Oy © 2024.03
19.8
(0.78)
69.3
(2.73)
8
4.5
(0.31)
(0.18)
189
196
(7.44)
(7.72)
1
(0.04)
AJ475942178716en-000101 / 172K2848A
