Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions of the Control Unit Mounting Plate
10.2.19
39.5
(1.55)
27.5
(1.08)
Ø5
(0.2)
20
(0.79)
3.5
(0.14)
212.25
(8.36)
Figure 145: Dimensions of the Modular Control Unit Mounting Plate in mm (in), 2 Places
Danfoss Drives Oy © 2024.03
16.75
(0.66)
234
(9.21)
AJ475942178716en-000101 / 172K2848A |
145
