Design Guide | iC7 Series Liquid-cooled System Modules
Wiring Diagram, INU, IR12L
10.3.4
1
DC+
DC-
DC+
DC-
1
DC fuses, loose option
3
Damping resistors
5
dU/dt Filter capacitors
Figure 161: Wiring Diagram, IR12L
Danfoss Drives Oy © 2024.03
2
U
DC+
V
DC-
W
INU
U
DC+
V
DC-
W
INU
3
U' U
V' V
W
W'
6
2
Inverter module IR12L
4
Output terminals
6
dU/dt Filter choke
U/T1
V/T2
W/T3
5
PE
