Danfoss iC7 Series Design Manual page 210

Design Guide | iC7 Series Liquid-cooled System Modules
DC voltage 594 V DC
¢
Switching frequency 2, 3, 4, or 6 kHz
¢
Modulator type 1
¢
Table 77: Power Loss for INU Modules without Options, Modulator Type 1
Model code Frame
iC7-60SLINB5-206AE0 IM10L
0F_
iC7-60SLINB5-245AE0 IM10L
0F_
iC7-60SLINB5-302AE0 IM10L
0F_
iC7-60SLINB5-385AE0 IM10L
0F_
iC7-60SLINB5-416AE0 IM10L
0F_
iC7-60SLINB5-525AE0 IM10L
0F_
iC7-60SLINB5-590AE0 IM12L
0F_
iC7-60SLINB5-650AE0 IM12L
0F_
iC7-60SLINB5-730AE0 IM12L
0F_
iC7-60SLINB5-820AE0 IM12L
0F_
iC7-60SLINB5-1060AE 2xIM1
00F_ 2L
iC7-60SLINB5-1230AE 2xIM1
00F_ 2L
iC7-60SLINB5-1400AE 2xIM1
00F_ 2L
iC7-60SLINB5-1500AE 2xIM1
00F_ 2L
210
| Danfoss Drives Oy © 2024.03
Rated System module,
curren 2 kHz switching
t I frequency
L(1/5)
[A]
Power Power
loss to loss
liquid to air
[kW] [kW]
206 1.18 0.01
245 1.45 0.01
302 1.87 0.02
385 2.58 0.03
416 2.88 0.03
525 3.15 0.03
590 3.64 0.04
650 4.18 0.04
730 4.80 0.05
820 5.63 0.06
1060 6.37 0.06
1230 7.67 0.08
1400 9.08 0.09
1500 9.96 0.10
System module, System module,
3 kHz switching 4 kHz switching
frequency frequency
Power Power Power
loss to loss loss to
liquid to air liquid
[kW] [kW] [kW]
1.39 0.01 1.60
1.69 0.02 1.94
2.17 0.02 2.49
2.99 0.03 3.42
3.33 0.03 3.81
3.65 0.04 4.19
4.22 0.04 4.84
5.79 0.06 5.47
5.57 0.06 6.37
6.52 0.07 7.44
7.43 0.07 8.51
8.94 0.09 10.22
10.54 0.11 12.06
11.55 0.12 13.23
System module,
6 kHz switching
frequency
Power Power Power
loss loss to loss
to air liquid to air
[kW] [kW] [kW]
0.02 2.03 0.02
0.02 2.46 0.02
0.02 3.17 0.03
0.03 4.37 0.04
0.04 4.88 0.05
0.04 5.33 0.05
0.05 6.16 0.06
0.05 6.97 0.07
0.06 8.13 0.08
0.07 9.58 0.10
0.09 10.79 0.11
0.10 12.98 0.13
0.12 15.34 0.15
0.13 16.87 0.17
