Danfoss iC7 Series Design Manual page 181

Design Guide | iC7 Series Liquid-cooled System Modules
Table 56: Source DC+ Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type (continued)
(1)
Model code
iC7-60SLDCxx-1440E00F4
iC7-60SLDCxx-1680E00F4
iC7-60SLDCxx-1920E00F4
iC7-60SLDCxx-2160E00F4
iC7-60SLDCxx-2400E00F4
iC7-60SLDCxx-2880E00F4
iC7-60SLDCxx-3240E00F4
iC7-60SLDCxx-3600E00F4
1) xx = B5 or 07
Source DC- Fuses for DC/DC Converter, IP00/Open Type
10.5.7
Table 57: Source DC- Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type
(1)
Model code
iC7-60SLDCxx-300AE00F4
iC7-60SLDCxx-360AE00F4
iC7-60SLDCxx-420AE00F4
iC7-60SLDCxx-480AE00F4
iC7-60SLDCxx-570AE00F4
iC7-60SLDCxx-720AE00F4
iC7-60SLDCxx-840AE00F4
iC7-60SLDCxx-960AE00F4
iC7-60SLDCxx-1080E00F4
iC7-60SLDCxx-1200E00F4
iC7-60SLDCxx-1440E00F4
iC7-60SLDCxx-1680E00F4
iC7-60SLDCxx-1920E00F4
iC7-60SLDCxx-2160E00F4
iC7-60SLDCxx-2400E00F4
Danfoss Drives Oy © 2024.03
Frame Rated Number
current of fuses
(I ) [A]
L
2 x DR12L 1440 6
1680 6
1920 6
2160 6
2400 6
3 x DR12L 2880 9
3240 9
3600 9
Frame Rated Number
current of fuses
(I ) [A]
L
DR10L 300 1
360 1
420 1
480 1
570 1
DR12L 720 2
840 2
960 2
1080 2
1200 2
2 x DR12L 1440 4
1680 4
1920 4
2160 4
2400 4
Fuse Part number
size (Mersen)
272 D272SG120V500QF
272 D272SG120V630QF
272 D272SG120V500QF
272 D272SG120V630QF
Fuse Part number
size (Mersen)
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD12C900TF
73
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD12C900TF
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD12C900TF
AJ475942178716en-000101 / 172K2848A |
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1200 500 2x3100
1200 630 2x4400
1200 500 3x3100
1200 630 3x4400
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1250 630 5900
1250 800 8900
1200 900 10200
1250 630 5900
1250 800 8900
1200 900 10200
1250 630 5900
1250 800 8900
1200 900 10200
181
