Design Guide | iC7 Series Liquid-cooled System Modules
Table 59: Current Ratings for Active Front-end Module, 525–690 V AC (640–1100 V DC) (continued)
Model code
iC7-60SL3A07-2650E00F4
iC7-60SL3A07-2940E00F4
iC7-60SL3A07-3120E00F4
iC7-60SL3A07-3600E00F4
iC7-60SL3A07-3900E00F4
iC7-60SL3A07-4320E00F4
iC7-60SL3A07-4750E00F4
iC7-60SL3A07-5040E00F4
iC7-60SL3A07-5400E00F4
iC7-60SL3A07-5750E00F4
1) cos φ = 1.00, efficiency = 98.0%, values calculated at 1025 V DC
2) LC Filter +AEZ1, LCL Filter +AEZ3 (grid side L Filter separate module)
3) Part of LCL Filter, +AEZ3
Current Ratings for AFE 380–500 V AC (465–800 V DC), IP00/Open Type
10.6.3
Table 60: Current Ratings for Active Front-end Module, 380–500 V AC (465–800 V DC)
(1)
Model code
iC7-60SL3AB5-261AE00F4
iC7-60SL3AB5-325AE00F4
iC7-60SL3AB5-380AE00F4
iC7-60SL3AB5-425AE00F4
iC7-60SL3AB5-475AE00F4
iC7-60SL3AB5-530AE00F4
iC7-60SL3AB5-595AE00F4
iC7-60SL3AB5-670AE00F4
iC7-60SL3AB5-760AE00F4
iC7-60SL3AB5-850AE00F4
iC7-60SL3AB5-945AE00F4
iC7-60SL3AB5-1040E00F4
184
| Danfoss Drives Oy © 2024.03
AC current
I [A] I [A] I [A]
N L H
2706 2650 1987
3002 2940 2205
3185 3120 2340
3675 3600 2700
3982 3900 2925
4410 4320 3240
4849 4750 3562
5145 5040 3780
5513 5400 4050
5870 5750 4312
AC current
I [A] I [A] I [A]
N L H
267 261 196
332 325 244
388 380 285
434 425 318
485 475 356
542 530 397
608 595 446
684 670 502
776 760 570
868 850 637
965 945 708
1062 1040 780
DC power, 690 V AC
(1)
mains
P [kW] P [kW]
L H
3104 2328
3444 2583
3655 2741
4217 3163
4568 3426
5060 3795
5564 4172
5903 4428
6325 4744
6735 5051
DC power, 500 V AC
(2)
mains
P [kW] P [kW]
L H
222 167
276 208
323 242
361 270
404 303
450 337
505 379
569 427
646 484
722 541
803 601
883 662
Frame Frame with
option +AEZ1
(2)
or +AEZ3
4 x AM12L 4 x AR12L
4 x AM12L 4 x AR12L
5 x AM12L 5 x AR12L
5 x AM12L 5 x AR12L
6 x AM12L 6 x AR12L
6 x AM12L 6 x AR12L
7 x AM12L 7 x AR12L
7 x AM12L 7 x AR12L
8 x AM12L 8 x AR12L
8 x AM12L 8 x AR12L
Frame Frame with
option +AEZ1
(3)
or +AEZ3
AM10L AR10L
AM10L AR10L
AM10L AR10L
AM12L AR12L
AM12L AR12L
AM12L AR12L
AM12L AR12L
AM12L AR12L
AM12L AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
AJ475942178716en-000101 / 172K2848A
Input
L Filter
size
(3)
[A]
2 x 1640
2 x 1640
3 x 1640
3 x 1640
3 x 1640
3 x 1640
4 x 1640
4 x 1640
4 x 1640
4 x 1640
Input
L Filter
size
(4)
[A]
400
400
400
1000
1000
1000
1000
1000
1000
1640
1640
1640
