Design Guide | iC7 Series Liquid-cooled System Modules
1
Figure 109: Connecting the Fieldbus Cable and the Fiber Cables
1
PLC (not included in the delivery)
3
Control board
5
Fiber cables
Installing the Control Cables into the Control Terminals
8.15
1.
Install the control cables into the control terminals.
See the pin numbering of the I/O and Relay Option in
1
2
3
Figure 110: Example of Installing the Control Cables
Danfoss Drives Oy © 2024.03
4
3
5
2
6
2
Fieldbus cable
4
Star coupler board
6
Power units
8.8 I/O and Relay Option
Connections.
AJ475942178716en-000101 / 172K2848A |
111
