Design Guide | iC7 Series Liquid-cooled System Modules
Table 58: Abbreviations Used in the Rating Tables (continued)
Abbreviation
P
L
P
H
S
L
Current Ratings for AFE 525–690 V AC (640–1100 V DC), IP00/Open Type
10.6.2
Table 59: Current Ratings for Active Front-end Module, 525–690 V AC (640–1100 V DC)
Model code
iC7-60SL3A07-236AE00F4
iC7-60SL3A07-300AE00F4
iC7-60SL3A07-334AE00F4
iC7-60SL3A07-380AE00F4
iC7-60SL3A07-425AE00F4
iC7-60SL3A07-475AE00F4
iC7-60SL3A07-530AE00F4
iC7-60SL3A07-595AE00F4
iC7-60SL3A07-670AE00F4
iC7-60SL3A07-760AE00F4
iC7-60SL3A07-850AE00F4
iC7-60SL3A07-945AE00F4
iC7-60SL3A07-1040E00F4
iC7-60SL3A07-1230E00F4
iC7-60SL3A07-1325E00F4
iC7-60SL3A07-1500E00F4
iC7-60SL3A07-1700E00F4
iC7-60SL3A07-1800E00F4
iC7-60SL3A07-2000E00F4
iC7-60SL3A07-2250E00F4
iC7-60SL3A07-2500E00F4
Danfoss Drives Oy © 2024.03
AC current
I [A] I [A] I [A]
N L H
241 236 177
307 300 225
341 334 250
388 380 285
434 425 318
485 475 356
542 530 397
608 595 446
684 670 502
776 760 562
868 850 637
965 945 708
1062 1040 780
1256 1230 922
1353 1325 993
1532 1500 1125
1736 1700 1275
1838 1800 1350
2042 2000 1500
2297 2250 1687
2552 2500 1875
Description
Output power, low overload (INU: motor power, AFE/GC: DC
power)
Output power, high overload (INU: motor power, AFE/GC: DC
power)
Apparent power, low overload
DC power, 690 V AC
(1)
mains
P [kW] P [kW]
L H
277 208
352 264
392 293
446 334
498 373
557 417
621 465
697 523
785 588
891 668
996 747
1107 830
1219 914
1441 1080
1552 1164
1757 1318
1992 1494
2109 1582
2343 1757
2636 1976
2929 2197
Frame Frame with
option +AEZ1
(2)
or +AEZ3
AM10L AR10L
AM10L AR10L
AM10L AR10L
AM10L AR10L
AM12L AR12L
AM12L AR12L
AM12L AR12L
AM12L AR12L
AM12L AR12L
AM12L AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
2 x AM12L 2 x AR12L
3 x AM12L 3 x AR12L
3 x AM12L 3 x AR12L
3 x AM12L 3 x AR12L
3 x AM12L 3 x AR12L
4 x AM12L 4 x AR12L
AJ475942178716en-000101 / 172K2848A |
Input
L Filter
size
(3)
[A]
400
400
400
400
1000
1000
1000
1000
1000
1000
1640
1640
1640
1640
1640
1640
2 x 1640
2 x 1640
2 x 1640
2 x 1640
2 x 1640
