Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions of the L Filter, 1640 A
10.2.13
8.5
(0.33)
23.5
(0.93)
65
(2.56)
100
(3.94)
Ø11.5 x 16.5
(0.45)
294
(115.7)
A
The connector on top of the filter
Figure 139: Dimensions of the L Filter, 1640 A
