Design Guide | iC7 Series Liquid-cooled System Modules
Table 47: Field Cable Sizes for INU Module, 525–690 V AC (continued)
Model code
iC7-60SLIN07-5300E00F
x
iC7-60SLIN07-5600E00F
x
iC7-60SLIN07-6100E00F
x
iC7-60SLIN07-6400E00F
x
1) IM10L, IR10L, IM12L, or IR12L
Marine Cable Sizes for AFE or GC Modules 525–690 V AC
10.4.5
Table 48: Cable Sizes for AFE or GC Module 525–690 V AC for Marine Applications (Marine cables according to IEC 60092-352)
Model code
iC7-60SLxx07-236AE00Fx
iC7-60SLxx07-300AE00Fx
iC7-60SLxx07-334AE00Fx
iC7-60SLxx07-380AE00Fx
iC7-60SLxx07-425AE00Fx
iC7-60SLxx07-475AE00Fx
iC7-60SLxx07-530AE00Fx
iC7-60SLxx07-595AE00Fx
iC7-60SLxx07-670AE00Fx
iC7-60SLxx07-760AE00Fx
iC7-60SLxx07-850AE00Fx
iC7-60SLxx07-945AE00Fx
iC7-60SLxx07-1040E00Fx
iC7-60SLxx07-1230E00Fx
iC7-60SLxx07-1325E00Fx
iC7-60SLxx07-1500E00Fx
Danfoss Drives Oy © 2024.03
I [A]
(1)
Frame
N
7 x Ix12L 5 410
5 720
8 x Ix12L 6 230
6 540
I [A]
(1)
Frame
N
Ax10L 245
310
345
390
Ax12L 435
490
545
610
690
770
2 x Ax12L 870
970
1070
1260
1360
1540
Motor cable Motor cable
2 2
Cu [mm ] Al [mm ]
28x(3x120+7 28x(3x150+4
0) 1)
28x(3x120+7 28x(3x185+5
0) 7)
32x(3x120+7 32x(3x185+5
0) 7)
32x(3x120+7 32x(3x185+5
0) 7)
Mains cable Cu Terminal max.
cable size
2
[mm ]
2x(3x70) 150 Cu/Al
2x(3x95) 150 Cu/Al
3x(3x70) 150 Cu/Al
3x(3x95) 150 Cu/Al
3x(3x95) 150 Cu/Al
3x(3x95) 150 Cu/Al
4x(3x95) 150 Cu/Al
4x(3x95) 150 Cu/Al
5x(3x95) 150 Cu/Al
5x(3x95) 150 Cu/Al
6x(3x95) 150 Cu/Al
6x(3x95) 150 Cu/Al
8x(3x95) 150 Cu/Al
8x(3x95) 150 Cu/Al
10x(3x95) 150 Cu/Al
10x(3x95) 150 Cu/Al
Terminal Number of
max. cable grounding
size terminals/
bolt size
300 Cu/Al 7/M8
300 Cu/Al 7/M8
300 Cu/Al 8/M8
300 Cu/Al 8/M8
Number of
grounding
terminals/
bolt size
1/M8
1/M8
1/M8
1/M8
1/M8
1/M8
1/M8
1/M8
1/M8
1/M8
2/M8
2/M8
2/M8
2/M8
2/M8
2/M8
AJ475942178716en-000101 / 172K2848A |
Max.
number of
cables/ bolt
size
28/M10
28/M10
32/M10
32/M10
Max. number
of cables/
bolt size
3/M8
3/M8
3/M8
3/M8
6/M10
6/M10
6/M10
6/M10
6/M10
6/M10
12/M10
12/M10
12/M10
12/M10
12/M10
12/M10
