Table 81: Technical Data (continued)
Technical item or function
Protections
Product compliance
Efficiency
Danfoss Drives Oy © 2024.03
Overvoltage trip limit
Undervoltage trip limit
Earth fault protection
Missing phase supervision
Overcurrent protection
Unit overtemperature protection
Motor overload protection
Motor stall protection
Motor underload protection
Conformity
Safety Standards
Functional safety
Marine type approvals
Efficiency
Technical data
Voltage class 07: 1250 V DC
Voltage class B5: 911 V DC
Set by parameter Unit Voltage Class
Voltage class B5:
Class 13, mains voltage 380–500 V AC: 334 V DC
Class 1, mains voltage 380–440 V AC: 334 V DC
Class 2, mains voltage 440–480 V AC: 390 V DC
Class 3, mains voltage 480–500 V AC: 503 V DC
Voltage class 07:
Class 13, mains voltage 525–690 V AC: 334 V DC
Class 1, mains voltage 525 V AC: 334 V DC
Class 2, mains voltage 600 V AC: 390 V DC
Class 3, mains voltage 690 V AC: 503 V DC
In TN and TT networks. Fulfills the requirements of IEC
60364-4-41 + AMD1, 411.
Not available for DC/DC converter modules.
Yes
Yes
Yes
Yes
Yes
Yes
CE, RCM, UA, UKCA.
See the product label of the drive for more approvals.
IEC/EN 61800-5-1 + A1
IEC/EN 62477-1 + A1
–
DNV, ABS, BV, CCS, RINA
See 10.7.1 List of Power Loss
