Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions of the Control Unit
10.2.18
Figure 144: Dimensions of the Control Unit in mm (in), Example Configuration
144
| Danfoss Drives Oy © 2024.03
83.4
(3.28)
234
(9.21)
297
(11.69)
79.3
(3.12)
AJ475942178716en-000101 / 172K2848A
