Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions of the Control Board
10.2.21
9.8
(0.38)
Ø4.8
(0.19)
Ø4
(0.16)
Figure 148: Dimensions of the Control Board in mm (in)
Danfoss Drives Oy © 2024.03
19.8
(0.78)
69
(2.72)
4.5
8
(0.18)
(0.31)
189
(7.44)
196
(7.72)
1
(0.04)
AJ475942178716en-000101 / 172K2848A |
147
