Design Guide | iC7 Series Liquid-cooled System Modules
DC Fuses for AFE or GC 640–1200 V DC, IP00/Open Type
10.5.3
Table 53: DC Fuses for AFE or GC 640–1200 V DC, IP00/Open Type
(1)
Model code
iC7-60SL3A0x-236AE00Fx
iC7-60SL3A0x-300AE00Fx
iC7-60SL3A0x-334AE00Fx
iC7-60SL3A0x-380AE00Fx
iC7-60SL3A0x-425AE00Fx
iC7-60SL3A0x-475AE00Fx
iC7-60SL3A0x-530AE00Fx
iC7-60SL3A0x-595AE00Fx
iC7-60SL3A0x-670AE00Fx
iC7-60SL3A0x-760AE00Fx
iC7-60SL3A0x-850AE00Fx
iC7-60SL3A0x-945AE00Fx
iC7-60SL3A0x-1040E00Fx
iC7-60SL3A0x-1230E00Fx
iC7-60SL3A0x-1325E00Fx
iC7-60SL3A0x-1500E00Fx
iC7-60SL3A0x-1700E00Fx
iC7-60SL3A0x-1800E00Fx
iC7-60SL3A0x-2000E00Fx
iC7-60SL3A0x-2250E00Fx
iC7-60SL3A0x-2500E00Fx
iC7-60SL3A0x-2650E00Fx
iC7-60SL3A0x-2940E00Fx
iC7-60SL3A0x-3120E00Fx
iC7-60SL3A0x-3600E00Fx
iC7-60SL3A0x-3900E00Fx
iC7-60SL3A0x-4320E00Fx
iC7-60SL3A0x-4750E00Fx
iC7-60SL3A0x-5040E00Fx
Danfoss Drives Oy © 2024.03
Frame Rated Number
current of fuses
I [A]
L
Ax10L 236 2
300
334
380
Ax12L 425 4
475
530
595
670
760
2 x Ax12L 850 8
945
1040
1230
1325
1500
3 x Ax12L 1700 12
1800
2000
2250
4 x Ax12L 2500 16
2650
2940
5 x Ax12L 3120 20
3600
6 x Ax12L 3900 24
4320
7 x Ax12L 4750 28
5040
Fuse Part number
size
73 PC73UD13C800TF
PC73UD12C900TF
73 PC73UD13C800TF
PC73UD12C900TF
73 PC73UD13C800TF
PC73UD12C900TF
73 PC73UD13C800TF
PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
