Design Guide | iC7 Series Liquid-cooled System Modules
Table 81: Technical Data (continued)
Technical item or function
Motor connection
Danfoss Drives Oy © 2024.03
Output voltage
Output frequency
Switching frequency, INU
Field weakening point
Motor control principles
Motor and generator types sup-
ported
Torque control, torque step rise time
Torque control, static accuracy
Speed control, static accuracy
Speed control, dynamic accuracy (re-
sponse)
Motor control resolution
Cable length
Technical data
0–U , 3-phase
in
0–599 Hz
1.5–10 kHz
Default: 3 kHz
Default: 8 kHz with +AES1
1–600 Hz
U/f control
VVC+ (Vector Voltage Control)
Flux Vector Control
Induction/asynchronous motor
Non-Salient Permanent Magnet Motor
Salient Permanent Magnet Motor
Synchronous Reluctance Assisted Permanent Magnet
Motor
Open loop: <5 ms with nominal torque and <1 ms with
nominal torque with AFE supply
Closed loop: <5 ms with nominal torque and <1 ms with
nominal torque with AFE supply
Open loop: <2% of motor nominal torque up to nomi-
nal speed and <4% of motor nominal torque in the field
weakening area
Closed loop: <2% of motor nominal torque up to nomi-
nal speed and <4% of motor nominal torque in the field
weakening area
Open loop: 5% of motor nominal slip up to motor nom-
inal motor frequency and 10% of motor nominal slip in
the field weakening area
Closed loop: 0.01% static error of nominal speed with en-
coder PPR of 1024 or better
Open loop: 0.2–0.4% s with nominal torque step
Closed loop: 0.1–0.2% s with nominal torque step
Reference setpoint resolution 31 bit + sign
Up to 150 m symmetrical and shielded motor cable. See
the cable restrictions for filters in
7.13.2 Common-mode Filter.
AJ475942178716en-000101 / 172K2848A |
7.13.1 dU/dt Filter and
