Design Guide | iC7 Series Liquid-cooled System Modules
Dimensions for the Control Panel Surface Mounting Kit
10.2.30
166
(605)
Figure 157: Surface Mounting Kit Drilling Template, mm (in)
Danfoss Drives Oy © 2024.03
108 (4.3)
Ø 3
(0.12)
28 (1.1)
Ø 41
(1.6)
Ø 3
(0.12)
53
(2.09)
56.5
(2.22)
AJ475942178716en-000101 / 172K2848A |
1.2
(0.5)
155
