Design Guide | iC7 Series Liquid-cooled System Modules
Inlet and Outlet Connectors of System Modules
6.4.6.3
INCORRECT INLET AND OUTLET CONNECTIONS IN THE COOLING SYSTEM
If inlet and outlet connectors are connected incorrectly, the cooling does not work as expected. Incorrect cooling can damage the
product.
Make the connections carefully.
l
Figure 47: Inlet Connectors of IM10L (left) and IM12L (right)
1
Inlet connectors
Figure 48: Outlet Connectors of IM10L (left) and IM12L (right)
1
Outlet connectors
54
| Danfoss Drives Oy © 2024.03
1
1
1
NOTICE
AJ475942178716en-000101 / 172K2848A
