Design Guide | iC7 Series Liquid-cooled System Modules
xR10L
1 2
Figure 124: Inlet and Outlet Connectors of System Modules with Integration Units xR10L and xR12L
1
Outlet connectors
3
Optional outlet connectors
1
Figure 125: Inlet and Outlet Connectors of the L Filter
1
Inlet/outlet connector
Draining the Power Units for xR10L and xR12L
9.7.2
Always drain the power units before storage or transportation.
Required for the draining procedure:
Tools for opening the quick-release connectors of the coolant inlet and outlet.
l
124
| Danfoss Drives Oy © 2024.03
xR12L
3
1 2 1 2
2
2
Inlet connectors
2
Inlet/outlet connector
3
AJ475942178716en-000101 / 172K2848A
