Danfoss iC7 Series Design Manual page 186

Design Guide | iC7 Series Liquid-cooled System Modules
Table 61: Current Ratings for Grid Converter Module, 525–690 V AC (640–1100 V DC) (continued)
Model code
iC7-60SLGC07-850AE00F4
iC7-60SLGC07-945AE00F4
iC7-60SLGC07-1040E00F4
iC7-60SLGC07-1230E00F4
iC7-60SLGC07-1325E00F4
iC7-60SLGC07-1500E00F4
iC7-60SLGC07-1700E00F4
iC7-60SLGC07-1800E00F4
iC7-60SLGC07-2000E00F4
iC7-60SLGC07-2250E00F4
iC7-60SLGC07-2500E00F4
iC7-60SLGC07-2650E00F4
iC7-60SLGC07-2940E00F4
iC7-60SLGC07-3120E00F4
iC7-60SLGC07-3600E00F4
iC7-60SLGC07-3900E00F4
iC7-60SLGC07-4320E00F4
186
| Danfoss Drives Oy © 2024.03
(1)
AC current
I [A] I [A] I [A]
N L H
868 850 637
965 945 708
1062 1040 780
1256 1230 922
1353 1325 993
1532 1500 1125
1736 1700 1275
1838 1800 1350
2042 2000 1500
2297 2250 1687
2552 2500 1875
2706 2650 1987
3002 2940 2205
3185 3120 2340
3675 3600 2700
3982 3900 2925
4410 4320 3240
Power, 690 V AC
mains
I [A] I [A] P [kW]
S1 S2 L
1275 1190 996
1417. 1323 1107
5
1560 1456 1219
1845 1722 1441
1988 1855 1552
2250 2100 1757
2550 2380 1992
2700 2520 2109
3000 2800 2343
3375 3150 2636
3750 3500 2929
3975 3710 3104
4410 4116 3444
4680 4368 3655
5400 5040 4217
5850 5460 4568
6480 6048 5060
Frame Frame
with
option
S [kVA]
L
+AEZ1
or
+AEZ3
1016 2 x 2 x
AM12L AR12L
1130 2 x 2 x
AM12L AR12L
1243 2 x 2 x
AM12L AR12L
1470 2 x 2 x
AM12L AR12L
1584 2 x 2 x
AM12L AR12L
1793 2 x 2 x
AM12L AR12L
2032 3 x 3 x
AM12L AR12L
2152 3 x 3 x
AM12L AR12L
2391 3 x 3 x
AM12L AR12L
2690 3 x 3 x
AM12L AR12L
2988 4 x 4 x
AM12L AR12L
3168 4 x 4 x
AM12L AR12L
3514 4 x 4 x
AM12L AR12L
3729 5 x 5 x
AM12L AR12L
4303 5 x 5 x
AM12L AR12L
4661 6 x 6 x
AM12L AR12L
5163 6 x 6 x
AM12L AR12L
AJ475942178716en-000101 / 172K2848A
Input
L Filter
size
(3)
[A]
(2)
1640
1640
1640
1640
1640
1640
2 x 1640
2 x 1640
2 x 1640
2 x 1640
2 x 1640
2 x 1640
2 x 1640
3 x 1640
3 x 1640
3 x 1640
3 x 1640
