Danfoss iC7 Series Design Manual page 196

Design Guide | iC7 Series Liquid-cooled System Modules
Table 68: Power Loss for AFE and GC Modules with Options +AEZ1 and +AEZ3 (continued)
Model code
iC7-60SL3A07-5040E00F_
iC7-60SL3A07-5400E00F_
iC7-60SL3A07-5750E00F_
1) System module and the LC Filter in the integration unit
2) System module and the LC Filter in the integration unit and the L Filter
3) DC fuses
Power Losses of AFE and GC Modules, Voltage Class B5
10.7.4
The specifications for the values in the table
l
AFE or GC module
¢
380–500 V AC (465–800 V DC)
¢
DC voltage 594 V DC
¢
Modulator type 4
¢
The default modulator type for grid converters is type 5, which results in slightly lower losses than given in the table.
n
Table 69: Power Loss for AFE and GC Modules
Model code
iC7-60SL3AB5-261A
iC7-60SL3AB5-325A
iC7-60SL3AB5-380A
iC7-60SL3AB5-425A
iC7-60SL3AB5-475A
iC7-60SL3AB5-530A
iC7-60SL3AB5-595A
iC7-60SL3AB5-670A
iC7-60SL3AB5-760A
iC7-60SL3AB5-850A
iC7-60SL3AB5-945A
196
| Danfoss Drives Oy © 2024.03
Frame Rated
current
I [A]
L(1/5)
7xAR12L 5040
8xAR12L 5400
8xAR12L 5750
Frame
AM10L
AM10L
AM10L
AM12L
AM12L
AM12L
AM12L
AM12L
AM12L
2xAM12L
2xAM12L
System module and System module and
(1)
+AEZ1 +AEZ3
Power Power Power
loss to loss to loss to
liquid air [kW] liquid
[kW] [kW]
91.0 3.96 -
95.0 4.13 98.5
103.8 4.51 107.8
Rated System module
current
Power loss
I [A]
L(1/5)
to liquid
[kW]
261 2.50
325 3.28
380 4.02
425 3.96
475 4.49
530 5.10
595 5.87
670 6.81
760 8.04
850 7.92
945 8.93
(3)
+AKFX
(2)
Power Power
loss to loss to
air [kW] air [kW]
- 0.46
6.44 0.38
7.16 0.53
(1)
+AKFX
Power loss Power loss
to air [kW] to air [kW]
0.03 0.02
0.03 0.02
0.04 0.03
0.04 0.01
0.05 0.02
0.05 0.03
0.06 0.04
0.07 0.05
0.08 0.07
0.08 0.02
0.09 0.04
AJ475942178716en-000101 / 172K2848A
Standby
loss,
system
module
and
+AEZ1
[kW]
0.96
1.10
1.10
Standby
loss [kW]
0.04
0.04
0.04
0.07
0.07
0.07
0.07
0.07
0.07
0.14
0.14
