Design Guide | iC7 Series Liquid-cooled System Modules
Table 68: Power Loss for AFE and GC Modules with Options +AEZ1 and +AEZ3
Model code
iC7-60SL3A07-236AE00F_
iC7-60SL3A07-300AE00F_
iC7-60SL3A07-334AE00F_
iC7-60SL3A07-380AE00F_
iC7-60SL3A07-425AE00F_
iC7-60SL3A07-475AE00F_
iC7-60SL3A07-530AE00F_
iC7-60SL3A07-595AE00F_
iC7-60SL3A07-670AE00F_
iC7-60SL3A07-760AE00F_
iC7-60SL3A07-850AE00F_
iC7-60SL3A07-945AE00F_
iC7-60SL3A07-1040E00F_
iC7-60SL3A07-1230E00F_
iC7-60SL3A07-1325E00F_
iC7-60SL3A07-1500E00F_
iC7-60SL3A07-1700E00F_
iC7-60SL3A07-1800E00F_
iC7-60SL3A07-2000E00F_
iC7-60SL3A07-2250E00F_
iC7-60SL3A07-2500E00F_
iC7-60SL3A07-2650E00F_
iC7-60SL3A07-2940E00F_
iC7-60SL3A07-3120E00F_
iC7-60SL3A07-3600E00F_
iC7-60SL3A07-3900E00F_
iC7-60SL3A07-4320E00F_
iC7-60SL3A07-4750E00F_
Danfoss Drives Oy © 2024.03
Frame Rated
current
I [A]
L(1/5)
AR10L 236
AR10L 300
AR10L 334
AR10L 380
AR12L 425
AR12L 475
AR12L 530
AR12L 595
AR12L 670
AR12L 760
2xAR12L 850
2xAR12L 945
2xAR12L 1040
2xAR12L 1230
2xAR12L 1325
2xAR12L 1500
3xAR12L 1700
3xAR12L 1800
3xAR12L 2000
3xAR12L 2250
4xAR12L 2500
4xAR12L 2650
4xAR12L 2940
5xAR12L 3120
5xAR12L 3600
6xAR12L 3900
6xAR12L 4320
7xAR12L 4750
System module and System module and
(1)
+AEZ1 +AEZ3
Power Power Power
loss to loss to loss to
liquid air [kW] liquid
[kW] [kW]
4.1 0.19 4.2
5.6 0.27 5.8
6.5 0.31 6.7
7.8 0.38 8.1
6.6 0.25 6.7
7.5 0.29 7.7
8.6 0.35 8.8
10.0 0.40 10.2
11.7 0.52 12.0
14.0 0.61 14.3
13.3 0.48 13.6
15.1 0.57 15.5
16.9 0.69 17.4
20.9 0.89 21.6
23.2 1.00 24.0
27.6 1.23 28.7
28.2 1.14 -
30.4 1.25 -
35.0 1.51 -
41.4 1.83 -
42.8 1.79 44.2
46.3 1.96 48.0
53.6 2.33 55.7
53.4 2.25 -
65.0 2.82 -
67.7 2.85 70.0
78.0 3.24 81.0
83.7 3.63 -
(3)
+AKFX
(2)
Power Power
loss to loss to
air [kW] air [kW]
0.27 0.01
0.40 0.02
0.47 0.02
0.59 0.03
0.32 0.01
0.38 0.02
0.46 0.03
0.54 0.04
0.69 0.05
0.84 0.07
0.71 0.02
0.85 0.04
1.03 0.04
1.35 0.07
1.55 0.10
1.95 0.13
- 0.11
- 0.09
- 0.14
- 0.20
2.76 0.17
3.07 0.19
3.71 0.28
- 0.18
- 0.33
4.44 0.25
5.24 0.40
- 0.34
