Design Guide | iC7 Series Liquid-cooled System Modules
Wiring Diagram, DC/DC Converter, DR12L
10.3.6
1
DC+
DC-
DC+
DC-
2
DC-
1
DC-bus fuses, option
3
DC/DC converter module DR12L
5
Source DC+ fuses, option
7
Capacitors
Figure 163: Wiring Diagram, DR12L
Danfoss Drives Oy © 2024.03
3
4
1
DC+
2
DC-
3
U'
U
PU1
V'
V
W'
W
1
DC+
2
DC-
3
PU2
PE
5
+
6
-
2
Source DC- fuses, option
4
DC-filter inductor
6
Discharging resistor
8
DC source/load
AJ475942178716en-000101 / 172K2848A |
8
7
161
