Design Guide | iC7 Series Liquid-cooled System Modules
Modulator type 2
¢
Table 74: Power Loss for INU Modules without Options, Modulator Type 2
Model code Frame
iC7-60SLIN07-170AE IM10L
00F_
iC7-60SLIN07-208AE IM10L
00F_
iC7-60SLIN07-261AE IM10L
00F_
iC7-60SLIN07-325AE IM10L
00F_
iC7-60SLIN07-365AE IM10L
00F_
iC7-60SLIN07-416AE IM10L
00F_
iC7-60SLIN07-465AE IM12L
00F_
iC7-60SLIN07-525AE IM12L
00F_
iC7-60SLIN07-590AE IM12L
00F_
iC7-60SLIN07-650AE IM12L
00F_
iC7-60SLIN07-730AE IM12L
00F_
iC7-60SLIN07-820AE IM12L
00F_
iC7-60SLIN07-945AE 2xIM12L
00F_
iC7-60SLIN07-1060E 2xIM12L
00F_
iC7-60SLIN07-1230E 2xIM12L
00F_
Danfoss Drives Oy © 2024.03
Rated System
curre module, 2
nt kHz switching
I frequency
L(1/5)
[A]
Power Power
loss to loss
liquid to air
[kW] [kW]
170 1.00 0.01
208 1.25 0.01
261 1.68 0.02
325 2.21 0.02
365 2.68 0.03
416 3.13 0.03
465 2.91 0.03
525 3.36 0.03
590 3.97 0.04
650 4.43 0.04
730 5.37 0.05
820 6.24 0.06
945 6.35 0.06
1060 6.73 0.07
1230 8.23 0.08
System System
module, 3 module, 4
kHz switching kHz switching
frequency frequency
Power Power Power
loss to loss loss to
liquid to air liquid
[kW] [kW] [kW]
1.20 0.01 1.47
1.49 0.02 1.83
1.95 0.02 2.37
2.57 0.03 3.15
3.00 0.03 3.93
3.60 0.04 -
3.40 0.03 4.27
3.93 0.04 4.93
4.54 0.05 5.82
5.14 0.05 6.50
6.00 0.06 7.87
7.05 0.07 -
6.93 0.07 9.31
7.95 0.08 9.88
9.57 0.10 12.07
AJ475942178716en-000101 / 172K2848A |
System
module, 6
kHz switching
frequency
Power Power Power
loss loss to loss
to air liquid to air
[kW] [kW] [kW]
0.01 1.83 0.02
0.02 2.27 0.02
0.02 2.99 0.03
0.03 - -
0.04 - -
- - -
0.04 5.15 0.05
0.05 5.97 0.06
0.06 6.94 0.07
0.06 - -
0.08 - -
- - -
0.09 11.40 0.11
0.10 11.95 0.12
0.12 - -
+AKF
(1)
X
Power
loss
to air
[kW]
0.01
0.02
0.02
0.04
0.04
0.05
0.03
0.04
0.06
0.07
0.08
0.11
0.05
0.08
0.11
