Danfoss iC7 Series Design Manual page 193

Design Guide | iC7 Series Liquid-cooled System Modules
10.7.7 Power Losses of INU Modules with +AEU1, Voltage Class 07, Motor Cable Maximum Length 50 m (164 ft)
l
10.7.8 Power Losses of INU Modules without Options, Voltage Class 07, Modulator Type 1 – SVPWM
l
10.7.9 Power Losses of INU Modules without Options, Voltage Class 07, Modulator Type 2 – Optimized
l
10.7.10 Power Losses of INU Modules with +AEU1, Voltage Class B5, Motor Cable Maximum Length 150 m (492 ft)
l
10.7.11 Power Losses of INU Modules with +AEU1, Voltage Class B5, Motor Cable Maximum Length 50 m (164 ft)
l
10.7.12 Power Losses of INU Modules without Options, Voltage Class B5, Modulator Type 1 – SVPWM
l
10.7.13 Power Losses of INU Modules without Options, Voltage Class B5, Modulator Type 2 – Optimized
l
10.7.14 Power Losses of DC/DC Converter Modules, Voltage Class 07
l
10.7.15 Power Losses of DC/DC Converter Modules, Voltage Class B5
l
Power Losses of AFE and GC Modules, Voltage Class 07
10.7.2
The specifications for the values in the table
l
AFE or GC module
¢
525–690 V AC (640–1100 V DC)
¢
DC voltage 1025 V DC
¢
Modulator type 4
¢
The default modulator type for grid converters is type 5, which results in slightly lower losses than given in the table.
n
Table 67: Power Loss for AFE and GC Modules
Model code
iC7-60SL3A07-236AE00F_
iC7-60SL3A07-300AE00F_
iC7-60SL3A07-334AE00F_
iC7-60SL3A07-380AE00F_
iC7-60SL3A07-425AE00F_
iC7-60SL3A07-475AE00F_
iC7-60SL3A07-530AE00F_
iC7-60SL3A07-595AE00F_
iC7-60SL3A07-670AE00F_
iC7-60SL3A07-760AE00F_
iC7-60SL3A07-850AE00F_
iC7-60SL3A07-945AE00F_
iC7-60SL3A07-1040E00F_
iC7-60SL3A07-1230E00F_
iC7-60SL3A07-1325E00F_
iC7-60SL3A07-1500E00F_
iC7-60SL3A07-1700E00F_
Danfoss Drives Oy © 2024.03
Frame Rated
current
I
L(1/5)
AM10L 236
AM10L 300
AM10L 334
AM10L 380
AM12L 425
AM12L 475
AM12L 530
AM12L 595
AM12L 670
AM12L 760
2xAM12L 850
2xAM12L 945
2xAM12L 1040
2xAM12L 1230
2xAM12L 1325
2xAM12L 1500
3xAM12L 1700
System module
Power loss Power loss
[A]
to liquid to air [kW]
[kW]
3.29 0.03
4.44 0.04
5.13 0.05
6.16 0.06
5.82 0.06
6.63 0.07
7.58 0.08
8.79 0.09
10.31 0.10
12.32 0.12
11.64 0.12
13.19 0.13
14.81 0.15
18.36 0.19
20.30 0.21
24.17 0.24
24.76 0.25
AJ475942178716en-000101 / 172K2848A |
Standby
(1)
+AKFX
loss [kW]
Power loss
to air [kW]
0.01 0.07
0.02 0.07
0.02 0.07
0.03 0.07
0.01 0.13
0.02 0.13
0.03 0.13
0.04 0.13
0.05 0.13
0.07 0.13
0.02 0.26
0.04 0.26
0.04 0.26
0.07 0.26
0.10 0.26
0.13 0.26
0.11 0.39
193
